首先CP243-1配置為CLIENT，使用STEP 7 Micro/WIN32中的向?qū)С绦?。在命令菜單中選擇工具一〉以太網向?qū)?br />步是對以太網通信的描述.點擊下一步開始以太網配置。在此處選擇模塊的位置，在線的情況下，您也可以用讀取模塊按鈕搜尋在線的CP243-1模 塊。導入SIEM089D.GSD文件，安裝EM277從站配置文件，如下圖：在SIMATIC文件夾中有EM277的GSD文件:導入GSD文件后，在右側的設備選擇列表中找到EM277從站， DP今Additional Field Devices今PLC今SIMATIC今EM277,并且根據您的通訊字節數，選擇一種通訊方式，本例



First, CP243-1 is configured as a client, and the wizard program in step 7 micro/win32 is used. Select tools I > Ethernet wizard in the command menu
The first step is the description of Ethernet communication Click next to start Ethernet configuration.
Select the location of the module here. When online, you can also use the read module button to search for the online CP243-1 module. Import siem089d GSD file, install EM277 slave configuration file, as shown in the following figure:
In SIMATIC folder, there is the GSD file of EM277:
After importing the GSD file, find the EM277 slave station, PROFIBUS DP today, additional field devices today, PLC today, SIMATIC today, EM277 in the device selection list on the right, and select a communication method according to your number of communication bytes, this example
