例子程序在OB1當中調用數據讀寫功能塊：SFC67和SFC68，如下圖:

分別在STEP7 MicroWin32和STEP7當中監視S7200和S7300 PLC當中的數據，數據監視見面如下:

  通過 CP5611，STEP7 MicroWin32， Set PG/PC Interface 可以讀取 S7200 和 S7300 的站地 址，如下圖：

站地址0代表的時進行編程的PG，即當前連接PLC的PC
2.S7-200 和 進行PROF US通信
  S7-300與S7-200通過EM277進行PROFIBUS DP通訊，需要在STEP7中進行S7-300站組態， 在S7-200系統中不需要對通訊進行組態和編程，只需要將要進行通訊的數據整理存放在V 存儲區與S7-300的組態EM277從站時的硬件I/O地址相對應就可以了 插入一個S7-300的站：

選中STEP7的硬件組態窗口中的菜單Option今Install new GSD

導入SIEM089D.GSD文件，

The example program calls the data reading and writing function blocks in ob1: sfc67 and sfc68, as shown in the following figure:
The data in S7200 and s7300 PLC are monitored in STEP7 microwin32 and STEP7 respectively. The data monitoring interface is as follows:
The station addresses of S7200 and s7300 can be read through CP5611, STEP7, microwin32, and set pg/pc interface, as shown in the following figure:
The PG that is programmed when the station address 0 represents, that is, the PC currently connected to the PLC
2. Profi US communication between S7-200 and S7-300
S7-300 and S7-200 communicate with PROFIBUS DP through EM277. It is necessary to configure the S7-300 station in STEP7. There is no need to configure and program the communication in the S7-200 system. Just sort and store the data to be communicated in the V storage area, which corresponds to the hardware i/o address of the S7-300 configuration EM277 slave station. Insert a S7-300 station:
Select the menu option install new GSD in the hardware configuration window of STEP7
Import siem089d GSD file,
